M600

Total Mass: 4.49–8.28 tons More Environmentally Friendly: Qingling’s China VI vehicles deliver low emissions and reduced fuel consumption throughout their entire lifecycle, while simultaneously enhancing overall vehicle performance—resulting in lower noise levels, less vibration, and a quieter, more comfortable driving experience. The vehicles fully comply with all China VIb emission standards. More Economical (Fuel‑Efficient and Urea‑Savings): With lower fuel consumption, these trucks achieve fuel savings of over 10%–15% compared to domestically produced vehicles with the same payload capacity. The urea injection volume is precisely calibrated, reducing user operating costs and making modifications more convenient for customers. High Reliability and Low Maintenance Costs. Stronger Fuel Compatibility: Taking into account China’s diverse fuel quality and users’ varying operating conditions, Qingling has developed its China VI models with optimized compatibility, significantly improving their ability to handle a wide range of fuel types—and enabling Qingling’s China VI vehicles to “eat rough” without issue. Higher Cost-Effectiveness: While prices for comparable China VI models in China have risen by 10%–20% or more compared to China V models, Qingling’s price increase is only a modest 3%–4%. More Powerful Performance: The engines deliver stronger power output, with comprehensive optimizations to both horsepower and low‑speed torque, resulting in improved full‑load performance and enhanced hill‑climbing capability across the entire vehicle lineup. More Variants Available: Qingling has expanded its product lineup to include a wider variety of configurations, such as sleeper cabs with one-and-a-half beds, composite panel cargo bodies, cage‑style cargo bodies, refrigerated trucks, and insulated trucks, offering users even more options to suit their specific needs.

Product Inquiry Contact Us

Product Introduction

Project	Single-row standard version (4×2)	Single-row, long‑axis heavy‑duty version (4×2)	Double-row standard version (4×2)	General / Customized for Foreign Trade
Brand and Model	Qingling Isuzu ISUZU M600 Light Truck	Qingling Isuzu ISUZU M600 Light Truck	Qingling Isuzu ISUZU M600 Light Truck	Diesel; Rear-wheel drive; Flatbed / Box van / Stake bed / Refrigerated / Special-purpose vehicle
Announced Model	QL1080BUHA / QL5048XXYBUHA	QL1080BUKA	QL1080BUHAY	Exports to Southeast Asia / Africa / the Middle East / South America / Eastern Europe
Drive Type	Front-wheel drive, rear-wheel drive (4×2)	Front-wheel drive, rear-wheel drive (4×2)	Front-wheel drive, rear-wheel drive (4×2)	Rear single wheel / Rear dual wheels available
Wheelbase	3365mm	3815mm	3365mm	Short axis is flexible; long axis is heavy‑duty.
Vehicle overall dimensions (length × width × height)	5995×2410×2440mm	7025×2410×2440mm	5995×2410×2440mm	Short-axis blue license compliant (≤6m); long-axis yellow license for heavy loads.
Cargo container dimensions (length × width × height)	4130×2150×380mm	5175×2150×380mm	3200×2150×380mm	Optional cargo box, gantry frame, tarpaulin, sealed compartment, refrigeration unit
Engine Model	4KH1CN6HB	4KH1CN6HB	4KH1CN6HB	Isuzu Classic 4K Series, B10 with a Long Service Life
Displacement	2.999L	2.999L	2.999L	China VIb / Euro V / Euro VI (Customized)
Maximum power	97 kW (132 hp) at 3,400 rpm	97 kW (132 hp) at 3,400 rpm	97 kW (132 hp) at 3,400 rpm	Powerful and stable, compatible with a wide range of operating conditions.
Maximum torque	320 N·m at 1600–2400 rpm	320 N·m at 1600–2400 rpm	320 N·m at 1600–2400 rpm	Low RPM, high torque—easy starting and hill climbing!
Gearbox	Isuzu MSB-6 / MYY-6S (6-speed manual)	Isuzu MSB-6 / MYY-6S (6-speed manual)	Isuzu MSB-6 / MYY-6S (6-speed manual)	All-aluminum housing, transmission efficiency of 98%+
Rear axle ratio	5.857 (standard); optional 5.375	5.375 (standard); optional 6.142	5.857 (standard); optional 5.375	Adapts to various operating conditions in high‑speed, plain, and mountainous terrains.
Curb weight	2850–3250 kg	3250kg	3000kg	Lightweight design, stronger load capacity.
Total mass	4495–8280 kg	8280kg	4495kg	Compliant payload, tailored to meet the regulations of different markets.
Rated load	1100–4835 kg	4835kg	1400kg	Blue license C1 is drivable; yellow license heavy-duty vehicles are highly efficient.
Fuel tank capacity	100L (optional 150L)	100L (optional 150L)	100L	Combined fuel consumption: 10–11 L/100 km; range: 900 km+
Tire specifications	7.00R16LT 8PR	7.50R16LT 14PR	7.00R16LT 8PR	Heavy-duty / wear‑resistant / fuel‑efficient tires available
Minimum ground clearance	190mm	200mm	190mm	Good off-road performance in urban, rural, and unpaved areas.
Braking System	Front disc, rear drum + ABS + EBD; optional air brake / air‑cut brake.	Front disc, rear drum brakes + ABS + EBD; air brake / air‑cut brake standard.	Front disc, rear drum + ABS + EBD; optional air brake / air‑cut brake.	Overloaded braking is safer.
Hanging	Front 3, Rear 4+2 leaf springs	Front 6, Rear 6+6 Leaf Springs	Front 3, Rear 4+2 leaf springs	800mm wide through‑beam, with a load capacity increased by 40%+
Cab	Single row, 3 seats, width 1995mm	Single row, 3 seats, width 1995mm	Double-row 5-seater, 1995mm wide.	Standard features include dual-zone automatic climate control, power windows, and central locking; optional features include a multi-function steering wheel and a rearview camera.
