600P

More Environmentally Friendly Qingling’s China VI vehicles deliver low emissions and fuel consumption throughout their entire lifecycle, while simultaneously enhancing overall vehicle performance—resulting in lower noise levels, reduced vibration, and a quieter, more comfortable driving experience. The vehicles fully comply with all requirements of the China VIb emission standard. More Economical (Fuel‑Efficient and Urea‑Savings) With low fuel consumption, these vehicles offer fuel savings of over 10%–15% compared to domestically produced trucks with the same payload capacity. The urea injection is precisely calibrated for high accuracy, reducing user operating costs and making retrofitting easier for customers. In addition, they boast high reliability and low maintenance expenses. Greater Fuel Compatibility Taking into account China’s diverse fuel quality and users’ varying operating conditions, Qingling has developed its China VI models with optimized compatibility, significantly improving their ability to handle a wide range of fuel types—and enabling Qingling’s China VI vehicles to “eat rough” without issue. Higher Cost-Effectiveness While prices for comparable China VI models in China have risen by 10%–20% or more compared to China V models, Qingling’s price increase is only a modest 3%–4%. More Powerful Performance The engines deliver stronger power output, with comprehensive optimization of both horsepower and low‑speed torque, resulting in improved full‑load performance and enhanced hill‑climbing capability across the entire vehicle lineup. More Variants Available Qingling has expanded its product lineup to include a wider variety of configurations, such as sleeper cabs with one-and-a-half berths, composite panel cargo boxes, cage‑style cargo boxes, refrigerated trucks, and insulated trucks, offering users even more options to suit their specific needs.

Product Inquiry Contact Us

Product Introduction

Total mass: 3.66–7.23 tons

Project	Single-row standard version (4×2)	Double-row standard version (4×2)	Single-row long-axle version (4×2)	General / Foreign Trade Configuration
Brand and Model	Qingling Isuzu 600P Light Truck	Qingling Isuzu 600P Light Truck	Qingling Isuzu 600P Light Truck	Blue plate / Yellow plate; Diesel; Rear-wheel drive; Flatbed / Box van / Stake bed / Refrigerated
Announced Model	QL1040A1HA / QL5040XXYA5HAJ	QL1040A1HW / QL1043BUHW	QL1070A5HAJ / NKR77PLLACJA	Exports to Southeast Asia / Africa / the Middle East / South America
Drive Type	Front-wheel drive, rear-wheel drive (4×2)	Front-wheel drive, rear-wheel drive (4×2)	Front-wheel drive, rear-wheel drive (4×2)	Rear single wheel / Rear dual wheels available
Wheelbase	3360mm	3360mm	3815mm	Short axis is flexible; long axis is heavy‑duty.
Vehicle overall dimensions (length × width × height)	5995×1880×2300mm	5950×1880×2300mm	6745×1880×2300mm	Blue Plate Compliance (≤6m)
Cargo container dimensions	4250×1784×380mm	3235×1790×380mm	5100×1880×380mm	Optional cargo box, gantry frame, tarpaulin, or sealed container.
Engine Model	4KH1CN5HS / 4KH1CN6LB	Same as left	Same as left	Isuzu Classic 4K Series, B10 with a Long Service Life
Displacement	2.999L	Same as left	Same as left	China V / China VIb / Euro V / Euro VI (Customized)
Maximum Power	96 kW (130 hp) at 3,400 rpm / 88 kW (120 hp) at 3,400 rpm	Same as left	Same as left	120/130 horsepower dual‑version
Maximum torque	290 N·m at 1500–2900 rpm	Same as left	Same as left	Low RPM, high torque—powerful start under heavy loads!
Gearbox	MSB-5SM (5-speed manual)	MSB-5SM	MSB-5SM / MLD-6Q	Genuine Isuzu, high transmission efficiency.
Rear axle ratio	5.375 / 6.142	Same as left	Same as left	Adapts to various operating conditions in high‑speed, plain, and mountainous terrains.
Curb weight	2565–2705 kg	2650kg	2640kg
Total mass	4495kg	4490kg	6770kg
Rated load	1495–1600 kg	1600kg	4000kg	Compliant payload; blue‑plate C1 vehicles are permitted to drive.
Fuel tank capacity	76L (optional 100L)	76L	76L	Combined fuel consumption: 9–10 L/100 km; range: 800 km+
Tire specifications	7.00R16 / 7.50R16	Same as left	Same as left	Heavy-duty / Wear‑resistant optional
Minimum ground clearance	180mm	180mm	180mm	Good road passability on urban/rural roads.
Braking System	Front disc, rear drum + ABS + EBD	Same as left	Same as left	Optional air brake / air‑cut brake (heavy‑duty version)
Hanging	Front leaf spring, rear multi-leaf spring	Same as left	Same as left	Heavy-duty and highly durable.
Cab	Single row, 2 seats	Double-row 5-seater	Single row, 2 seats	Standard features include hot and cold air conditioning, a radio, and USB.
